Technical Specifications:

Product

Panmasala, Tobacco, Jaljira, coffee Powder, Detergents

Quantity to be packed

1 gm - 200 gm

No. Of Tracks

4 -10 tracks (Depends upon pouch width)

Machine Speed

65 -70 Pouch / Min. / Track

Temperature Controller

PID Based

Machine Control

PLC (Programmable Logic Control) Based

Filling system

Slide Filler

Roll Diameter

400 -800 mm

Contact Parts

Food Grand Stainless Steel SS 316 / SS 304

Pouch Length / Type

Programmable / Four Side Sealing (With / Without Gussets)

Laminate Unwinding System

Servo Based / Electromagnetic clutch and break

Web Controller

Electronic / Pneumatic Hydraulic Web Edge Controller

Compressed Air requirement

2 CFM @ 6 Bar

Electric Supply

440 V, Three Phase, 50 Hz

Power consumption

5 -9.5 kW

Machine Dimension & Weight

L (4000) x W (1600) x H (2750) mm , 1200- 2100 KG

Optional Attachments

Pneumatic Coding Device, Collating System, Notching.
